Crimp With 10% of the Effort. 100% of the Power.

Product Introduction

“Your hands have had enough. By 2 p.m., your wrist aches from the repetitive squeeze‑release‑squeeze of a manual crimper. Your forearm is tight. You’ve still got three more control cabinets to wire before the day ends, and every connector feels like it’s fighting back harder than the last one.

You didn’t get into this trade to have your body clock out before you do.

Now picture this instead. You pick up a tool that weighs less than a full water bottle. You place it over the terminal and squeeze gently—just enough to hold it in place. The tool senses the resistance and the motor takes over. A quiet hum, a soft click, and in under a second and a half, it’s done. You release, move to the next connector, and repeat. Not a single bead of sweat on your palm. Not a single twinge in your wrist. By the time you’ve finished the panel, your hand feels as fresh as when you started.

That’s what happens when a tool takes on 90% of the work.

It covers everything from delicate 0.14 mm² signal wires to 50 mm² power cables, with interchangeable dies that swap in seconds. One battery charge delivers up to 300 crimps on standard copper terminals—more than enough for a full day of panel building or field installation. When the light fades, the built-in LED illuminates the crimping area so you can keep working safely.

This isn’t just a faster crimper. It’s a way to go home at the end of the day without your hands still holding the shape of a tool.”

Product Features

⚡ Effort‑Sensing Technology: Your Hand Just Holds. The Motor Does the Work.
“Apply 10% of the force. The tool senses it and takes over.”
“You grip the terminal gently—just enough to position it. The built-in sensor detects the pressure and instantly engages the motor, which delivers up to 15 kN of force through the die set. You’re not fighting a spring. You’re not squeezing with white knuckles. You’re simply holding the tool steady while the precision mechanism completes a perfect, gas‑tight crimp every single time. No inconsistent pressure. No rework. Just finished connectors, one after another.”
🔋 Under 1.5 Seconds Per Crimp: Speed That Compounds
“Think of every panel you’ve ever wired. Now imagine finishing it in half the time.”
“One crimp takes less than a second and a half. Over the course of a control cabinet with 200 terminations, that speed translates to finishing the crimping work in minutes rather than hours. The electronic lock ensures the die fully closes before releasing, so you never have to second‑guess whether the connection is solid. It’s speed without sacrifice.”
🎯 300 Crimps on One Charge: A Full Shift Without Interruption
“Start the day with a fresh battery. Finish the panel before the light blinks.”
“The 10.8V lithium‑ion battery delivers approximately 300 crimps on standard 10 mm² copper terminals. That’s enough for a full day of panel building or multiple field installations. The charge level indicator tells you exactly where you stand, and if you do need to top up, the battery recharges in about 40 minutes—less time than a lunch break.”
🛡️ Ergonomic Design That Remembers You’re Human
“Less than 1 kg. In‑line balance. A grip that doesn’t punish your palm.”
“The entire tool, battery included, weighs just 0.96 kg—about the same as a bag of sugar. The inline design keeps the centre of gravity balanced in your hand, so you’re not fighting a front‑heavy nose. The two‑component housing absorbs vibration and provides a secure grip even with gloved hands. An attachment point lets you clip it to a balancer or lanyard when working at height. Every detail is built around the person holding it.”

Product Specifications

• Crimping Range: 0.14 – 50 mm² (insulated & uninsulated terminals)

• Max Crimping Force: 15 kN

• Crimping Cycle: < 1.5 seconds (depending on connection material)

• Battery Voltage / Capacity: 10.8 V / 1.5 Ah Li‑ion

• Weight (with battery): 0.96 kg

• Charging Time: ~40 minutes

• Operating Temperature: -10°C to +40°C

Packaging Includes

• Electro‑Mechanical Crimping Tool × 1 (with PowerSense technology)

• 10.8V Li‑ion Battery (RAML1) × 1

• Battery Charger (230V) × 1

• Plastic Carry Case × 1

• User Manual × 1

🎯“Your hands work hard enough. Stop asking them to supply the crushing force of a hydraulic press.
Get the tool that delivers 15 kN of force with 10% of the effort, and finish your next panel with your wrists still ready for tomorrow.
